Powder Stick Pack Machine

Application of Auto Powder Packing Machine
Powder packing machine is widely used in is widely used to pack powder materials, milk powder, milk tea powder, coffee powder, spices, curry powder, protein powder, condiment, herbal powder, washing powder, soap powder and other chemical and medical powders.



Main Features


1.With the function auto filling, measuring, bag forming, code printing, sealing and cutting. Bag-making system adopts step motor
with high precision


2.Touch screen display.


3. Controller adopts Chinese or English displaying, can see the working conditions directly.


4. With intelligent photoelectric controller system.


5. Machine body full of 304 stainless steel.


6. Auger filler, high accuracy.


7. Good visibility with side-open protective platens, operate safely.


8. Adopt the newest hopper sets, easy to adjust and clean, no need adjust again after clean, so that can improve working
efficiency


9. This machine is suitable for the packing of powder products, bag can choose from 3-side or 4-side seal or back seal according
to customer needs.


10. Ribbon printer is addable according to customer needs, which can print one to three lines letter, date of produce and batch number.







Main Technical Parameter



Machine Model: HTL-400F
Bag-Making Size Range: (L)30-200mm,(W)30-150mm
Film Width Range: 80mm-320mm
Packing Filling Range: 1g-300g
Packing Speed Range: 30-70bags/min
Film Thickness Range: 0.04mm - 0.08mm
Packing Material: Paper. OPP/CPP. Pet/PE. Pet-Al/PE Composite Material
Film Roll Diameter: Max. 320mm
Power Supply: AC220V 50/60Hz 2.5kw
Packing type: All of kinds of powder
Machine Dimension: (L)1100*(W)820*(H)2150mm
Machine Weight: 300kg
