Characteristic:

1. It is suitable for the measurement and packaging of granules, powders, liquids, sauces and other items in the food industry.
2. It can automatically complete the functions of bag making, measuring, cutting, sealing, cutting, counting, printing batch number and other functions according to customer requirements.
3. Touch screen operation, PLC control, same server motor control bag length, stable performance, convenient adjustment, accurate detection. Intelligent temperature controller, PID adjustment, to ensure that the temperature error range is controlled within 1%C.
Packaging material: PE composite film, such as: pure aluminum, aluminum, nylon, etc.


Technical Parameters:
Measurement range: 1-20ml
Bag size: Length (L): 30-180 mm Width (W): 20-60 mm
  Capacity: 20-35bags/min
Voltage power: 220V/50 - 60HZ/5.5KW
Dimensions: 930*1500*2400mm
Machine weight: 400KG
Air source: 0.3m/min( 0.6-0.8Mpa )
